FAW J6P 6x4 430HP Dump Truck
The Faw 430hp 6x4 Dump Truck stands out as one of the most balanced and dependable heavy-duty trucks in the FAW lineup. It provides strong power output, stable driveline performance, and a durable structure designed to handle frequent loading and long-distance material transport.
- FAW
- China
- 15-20 days
- 100 units per month
- Information
Faw 430hp 6x4 Dump Truck — Stronger Power for Heavy Material Transport
The Faw 430hp 6x4 Dump Truck is designed for demanding transport operations that benefit from higher horsepower. With a 430hp output, this model offers additional pulling force, stable torque delivery, and quicker response under heavy load conditions. Its chassis and 6×4 driveline work together to support long operating hours on busy construction and mining routes.
Main Benefits
Upgraded 430hp Engine Performance
The 430hp powertrain provides a balance of strength and efficiency. This model accelerates smoothly with loaded material and maintains steady power for inclines, uneven terrain, and long working days. Its characteristics meet the needs of buyers seeking performance above the 380hp–420hp range.
Durable 6×4 Configuration with Optional 8×4
The standard 6×4 setup provides strong traction and structural stability for compact and medium–heavy loads. For increased body volume or higher payload requirements, an optional 8×4 configuration can be selected to expand capacity.
Solid Construction and Daily Reliability
FAW’s structural engineering ensures a durable frame, reinforced body support, and dependable axle integration. The layout promotes consistent performance during repetitive load-and-dump cycles common to quarry, mining, and construction operations.
Technical Specifications
Key specifications for the Faw 430hp 6x4 Dump Truck are listed below.
| English Translation | Description |
|---|---|
| Drive Type | 6X4 |
| Wheelbase | 4050 + 1350 mm |
| Engine | Xichai CA6DM2 430hp (Euro 2/3/4 options) |
| Transmission | FAW CA12TAX230M |
| Vehicle Length | 8.74 meters |
| Vehicle Width | 2.55 meters |
| Vehicle Height | 3.4 meters |
| Front Track | 2048 mm |
| Rear Track | 1878 / 1878 mm |
| Curb Weight | 12.5 tons |
| Rated Load | 12.37 tons |
| Total Mass (GVW) | 25 tons |
| Approach Angle | 24 degrees |
| Departure Angle | 25 degrees |
Recommended Applications
This 430hp configuration is ideal for mine transport, large stone haulage, high-volume earthmoving, and long-run construction transfers. Its additional power shortens turnaround time and maintains speed on hilly routes.
Vehicle Strengths and Component Design
Reinforced Dump Body Compatibility
The chassis supports multiple dump body types including rock bodies, U-shape bodies, and standard box bodies with adjustable side height and plate thickness. This allows tailoring to the materials commonly transported.
Cab Ergonomics and Driver Focus
The cabin offers clear visibility and user-friendly control placement, helping reduce fatigue during long shifts. The layout also supports consistent handling, especially on job sites with frequent maneuvering.
Reliable Powertrain Integration
The 430hp engine and FAW transmission combination ensures predictable shifting and steady torque. Cooling and lubrication systems are arranged for high-duty operation, maintaining performance through long cycles.
Options & Customization
Dump Body Configurations
Available configurations include adjustable capacity, hydraulic cylinder options, rear gate variants, and stronger floor panels for handling abrasive materials.
Axle Ratio Choices
Custom axle ratios can be selected to match long-distance transport or steep-grade sites, enhancing either fuel economy or pulling force depending on the requirement.
Multi-Horsepower Lineup
Alongside the Faw 430hp 6x4 Dump Truck, the FAW lineup includes 350hp, 380hp, 390hp, 400hp, and 420hp versions to provide a wide range for buyers with differing job demands.
About ZW Group
ZW Group supplies a comprehensive line of heavy-duty vehicles to international customers. Our catalog includes FAW dump trucks such as the Faw 430hp 6x4 Dump Truck, plus a full selection of Shacman fuel tank trucks and dump trucks. For tractor needs, we also offer Howo tractor trucks in multiple horsepower ratings. This diverse mix gives buyers flexibility to match equipment with their operational demands.
Contact & Quotation
For pricing, stock details, customization options, or shipment arrangements for the Faw 430hp 6x4 Dump Truck, contact ZW Group for fast support. Our team can provide recommendations suited to your working conditions.
